- Size: 100
- Place of Origin: Tower F1, Qilu Software Park, Hi-tech Zone,Jinan, Shandong Province, China
- Brand Name: Sheenrun
- Model Number: SHR-VLV350
- Weight: 7.500 kg
● Update online,Chinese and English menu
● Adopt laser IR illuminator system,illuminate far with large scope,can realize monitoring in 0Lux
● Day and night type low illumination level color to black camera,to realize monitoring around the clock
● Shift speed pan-tilt, realize whole monitoring and high precision orientation
● High intelligence,simply operation,easy use and maintenance
● Good concealing,not easy to be found
●Smart shell with professional design,light,firm,high temperature resistance,anti-corrosion, waterproof and acid rain proof
● Low power consumption,few heat generated,stable work performance
Monitoring Distance | Night vision | 300m |
Day vision | 400m | |
CCD camera | Pixel | 440000 pixel |
TVL | 540 TVL(Color);570 TVL(Black &white) | |
Focal length | 4.1~73.8mm,18x optical zoom | |
Iris | F1.4~3.0 | |
FOV | 2.8°~48° | |
Laser IR illuminator | Wave length | 810nm,5w |
Illuminate angle | 2°~50°,sync zoom | |
Light homogenization | RML | |
Pan-tilt | Speed | Pan 0°~80°/s,Tilt 0°~60°/s |
Angle | 360° continuously rotating horizontally,-90°~ 90° looking up and down | |
Presets | Max 128 | |
Cruising paths | 6 cruising paths,each path can set up 20 presets | |
Others | 40s self-checking,power off memory | |
Interface | Power supply interface | AC24V |
Other interface | RS485,BNC video output | |
Environmental indicators | Working temperature | -25℃~ 55℃ |
Storage temperature | -40℃~ 65℃ | |
International protection | IP65 | |
Anti-vibration | GB/T 4857.10-2005 | |
Anti-impact | GB/T 15412-94 Free drop test method | |
Thunder proof | 2000V | |
Power | Power supply | AC24V±10%/3A |
Power consumption | 45W | |
Physical features | Weight | 7.5kg |
Size | 374×218×243(mm) | |
Installation | Outdoor base install |
